Diffuse Reflections Lens RGBW DMX512 LED Module - Linear Modules with 6 LEDs - 24V - 20-Pack
Diffuse DMX512 RGBW LED modular light uses 3030 LED beads with optical lenses to create an even and bright illumination. The 175-degree beam illuminates a wider area, reducing dark areas and light spots. And the high color rendering index (CRI) allows this RGBW LED module to reproduce the color of objects well. The LED module light source contains 20 pieces of modules, each piece has 6 pieces of 3030 LED chips and one piece of UCS512C4 chip. The UCS512C4 IC can accurately decode DMX512 signals, receiving commands from the DMX master controller to achieve precise color control and create rich dynamic lighting effects. These features make it widely used in advertising light boxes, channel letters, sign lighting, etc. Each module of the modular LED light can be separated into individual units, making it ideal for irregular light boxes or DIY projects.
The RGBW module light can not only mix colors to produce millions of different colors, but also provide additional white light, which improves the flexibility of application. The DMX module light features stable signal and strong anti-interference capabilities, making it ideal for large-scale lighting projects. Compared with SPI module lights, DMX module light support for up to 512 channels, making it excels in scenarios requiring unified control. In addition, it uses aluminum substrate with superior heat dissipation performance, which helps to extend the service life of LEDs.
A 24V power supply is required when using this diffuse reflective lens LED Module Light.
Features
1. 20pcs/string, every peice has 6 3030 LED beads.
2. The IC type is UCS512C4, each module has one IC.
3. The color is RGBW.
4. Can be cut every peice, making it ideal for adapting to irregular lightboxes.
5. The beam angle is 175 degrees.
6. The wire length between modules is 20cm/ 7.87in.
Specification
LED Strip Type: Diffuse Reflection Lens LED Module Lights
Wire Length: 20cm/PCS
Input Voltage: DC 24V
Size: 70mm*70mm
Power: 4.8W/PCS
IC Type: UCS512C4
IC Quantity: 1 Pix/PCS
LED Color: RGBW
LED Quantity: 6LEDs/PCS
Quantity: 20PCS/String
Cut: 1 Peice/Cut
Beam Angle: 175°
CRI: 85+
Material: Aluminum
LED Chip: 3030
Central Distance: 270mm/10.62in
Channel Timing: RGBW
Adhesive Backing: Yes
